Product Details:
Payment & Shipping Terms:
|
| Material: | Carbon Steel Wire, Galvanized Wire | Mesh Opening: | 1"x1",1-1/2"x1-1/2",2"x2",2"x1"etc. |
|---|---|---|---|
| Wire Diameter: | 0.4mm - 6.0mm | Panel Size: | 1.2x2.4M,1.2x3.0M,1.8x3.6M Ect. |
| Surface Treatment: | PVC Coating | Post Height: | 1.1M-3.0M |
| Highlight: | Galvanized Curved Fence Welded Mesh Fence,3D Curved Fence Welded Mesh Fence,Post 3d curved wire mesh fence |
||
Galvanized 3D Curved Fence Welded Mesh Fence with Ground Post
It is an economical version of the panel system, constructed from a welded mesh panel with longitudinal profiles that forms arigid fence. The fence panel is welded with high quality low carbon steel wire, surface treated by electrostatic polyester powder spray coating over galvanized materials, then connected with post by suitable clips. Due to its simple structure, easy installation, nice appearance, more and more customers regard welded mesh fence as the preferred common protective fence.
3d curved welded wire mesh fence is a type of welded wire mesh which has V-shaped strengthen bending curves. It is made of high quality low carbon steel wire, galvanized steel wire,metal column connected. The surface treatment of Triangle bend fence includes: hot-dipped galvanized, PVC coated, powder coated, polyester coated.
|
Specification of 3D Bend Fence
|
|
|
Mesh Opening
|
50x100mm/50x150mm/50x200mm/55x200mm/75x150mm
|
|
Wire Diameter
|
3.0/3.5/4/4.5/5.0mm
|
|
Panel Height
|
0.6m-3.0m ( Suggest size : 2m/2.4m/3m )
|
|
Panel Width
|
2.0m-3.0m ( Suggest size : 2m/2.5m/2.9m )
|
|
|
Round Post : 48x1.5/2.0mm 60x1.5/2.0mm
|
|
Square Post(SHS) : 50X50x1.5/2.0mm 60x60x1.5/2.0mm 80x80x1.5/2.0mm
|
|
|
Rectangular Post(RHS) : 40x60x1.5/2.0mm 40x80x1.5/2.0mm
60x80x1.5/2.0mm 80x100x1.5/2.0mm |
|
|
Surface Treatment
|
hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating
|
|
Color
|
RAL 6005 green, RAL 7016 gray, All RAL color can be customized
|
|
Note
|
The fence can be customized according to your required if above specification is not satisfied with you
|
|
Contact Now
|
Most of the panels are customized, please let us know your request.
|
A set of 3D curved welded wire mesh fence include:
1. welded wire mesh panel
2. fence post and post cap
3. clamps
Tips:
You can only tell us fence height and total length you need, we will give you a suitable suggestions.
| 3D curved PVC coated galvanized welded iron wire mesh fence panel | |
| material | steel iron wire,galvanized wire |
| surface treatment | PVC coated ,powder coated |
| color | blue,green,black,white,yellow,grey,etc. |
| wire diameter | 4.5mm,5mm,6mm |
| hole size | 50x200mm,75x200mm |
| fence height | 1.5m,1.6m,1.8m,2m,2.1m |
| fence length | 2m,2.5m |
| post | peach type post,square type post |
